This domestic water booster set is designed for the automatic water supply of homes, households or irrigation systems, using water from wells, boreholes or storage tanks. Thanks to the integrated self-adapting pressure switch, the pump automatically sets the start and stop pressure according to the installation. If the automatically set start pressure does not meet the requirements of the installation, it can be adjusted manually. It is equipped with a filling port for easy priming of the pump before operation.
The system operates automatically, starting and stopping the pump according to the set pressure, providing convenience and efficiency in use.
With a power of 900 W (682543) / 1300 W (682544), the booster set allows suction of water from a depth of up to 8 m and pumping to a maximum head of 44 m (682543) / 53m (682544), ensuring a maximum flow rate of 108 L/min (682543) / 125 L/min (682544). The 24 L expansion vessel helps to reduce the number of pump starts, extending the service life of the equipment. The pump body is made of corrosion-resistant materials ABS + stainless steel, offering increased durability and reliability in long-term operation. The tank is made of electrostatically painted steel, providing high resistance, and the interior is fitted with a high-quality EPDM membrane, an elastic material resistant to pressure variations.
Technical data:
Rated power: 900 W (682543) / 1300 W (682544)
Maximum suction depth: 8 m
Maximum pumping height: 44 m (682543) / 53m (682544)
Maximum flow rate: 108 L/min (682543) / 125 L/min (682544)
Maximum working pressure: 4.4 bar (682543) / 5.3 bar (682544)
Tank volume: 24 L
Maximum pumped liquid temperature: 35°C
Filter: No
Protections: thermal, with automatic reset
Connection: 1”
Protection rating: IPX4
Noise level: 79 dB(A) (682543) / 88 dB(A) (682544)
Net weight: ~ 12.5 kg (682543) / ~ 13.5 kg (682544)
Booster sets must be installed in locations protected from weather conditions and away from areas with high humidity.
To protect the booster set and the installation, it is recommended to install a particle and impurity filter, or a filter protecting against lime scale deposits (as appropriate), on the supply line, BEFORE the booster set.
Do not use the product to extract hydrocarbons (fuels, oils, solvents, etc.) or other liquids.
