This submersible pump is designed to extract clean water from boreholes or wells of medium or great depth. Thanks to its multistage construction and series-connected impellers, it generates high pressures and ensures a steady flow.
Its 4” diameter makes it compatible with most borehole casings, ensuring easy handling and installation.
With a power rating of 750 W (683016) / 1100 W (684294), the submersible pump can lift water to a maximum height of 74 m (683016) / 108 m (684294), delivering a maximum flow rate of 28.3L/min (683016) / 32.4 L/min (684294).
The stainless steel body offers superior corrosion resistance, a longer service life and increased reliability, making the pump ideal for prolonged use in damp outdoor conditions.
Technical Data:
Rated power: 750 W (683016) / 1100 W (684294)
Maximum immersion depth: 30 m (683016) / 30 m (684294)
Maximum pumping head: 74 m (683016) / 108 m (684294)
Maximum flow rate: 28.3L/min (683016) / 32.4 L/min (684294)
Maximum pressure: 8 bar (683016), 10.8 bar (684294)
Power cable length: 15 m
Maximum pumped liquid temperature: 70 °C
Connection: 1”
Protection rating: IP68
Do not use the product to extract hydrocarbons (fuels, oils, solvents, etc.) or other liquids!
